Arduino ABX00029 MKR WAN 1310
The MKR WAN 1310, brings in a series of improvements when compared to its predecessor, the MKR WAN 1300
Descrizione
Descrizione
Better and More Efficient
The MKR WAN 1310, brings in a series of improvements when compared to its predecessor, the MKR WAN 1300. While still based on the Microchip® SAMD21 low power processor, the Murata CMWX1ZZABZ LoRa® module, and the MKR family’s characteristic crypto chip (the ECC508), the
MKR WAN 1310 includes a new battery charger, a 2MByte SPI Flash, and improved control of the board’s power consumption.
Improved Battery Power
The latest modifications have considerably improved the battery life on the MKR WAN 1310.
When properly configured, the power consumption is now as low as 104uA! It is also possible to use the USB port to supply power (5V) to the board; run the board with or without batteries -the choice is yours.
On-board Storage
Data logging and other OTA (Over The Air) functions are now possible since the inclusion of the on board 2MByte Flash. This new exciting feature will let you transfer configuration files from the infrastructure onto the board, create your own scripting commands, or simply store data locally to send it whenever the connectivity is best. Whilst the MKR WAN 1310’s crypto chip addsfurther security by storing credentials & certificates in the embedded secure element.
These features make it the perfect IoT node and building block for low-power wide-area IoT devices.
Related Boards
If you are still deciding about the right wireless protocol for your solution, Arduino's MKR family has some alternatives to offer:
● MKR FOX 1200: for your EU solutions on Sigfox infrastructure.
● MKR GSM 1400: when looking at global coverage, GSM / 3G is the world's most extended network. Visit its product page here. We also provide you with a bundle including the board and a SIM with a global data plan in case you need it.
● MKR NB 1500: if your solution is designed around Narrowband IoT.
Getting Started
The Getting Started section contains all the information you need to configure your board, use the Arduino Software (IDE), and start tinkering with coding and electronics.
Arduino IoT Cloud Compatible
Use your MKR board on Arduino's IoT Cloud, a simple and fast way to ensure secure
communication for all of your connected Things.
*The following boards connect to the Arduino IoT Cloud via The Things Stack, a LoRaWAN® Network Server connected to thousands of public LoRa® gateways.
Scheda tecnica
| Articolo | 670047528 |
| Tempo medio consegna (giorni calendario) | 25 |
| Paese di provenienza | 86 |
| Codice TARIC | 85429000 |
| Manufacturer Part Number | ABX00029 |
| Quantità di vendita | 1 |
| Unità di Misura di vendita | PZ |
| Descrizione breve | The MKR WAN 1310, brings in a series of improvements when compared to its predecessor, the MKR WAN 1300 |
